Product Detailed Parameters
- Description：CONN HEADER VERT 12POS 2.54MM
- Series：EconoStik™ 10129381
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：12
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：0.120" (3.05mm)
- Overall Contact Length：0.538" (13.67mm)
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) 10129381-912003BLF is a pin header from the EconoStik series, designed for board-to-board connections. It features a 2.54 mm pitch with 12 contacts arranged in two rows. The connector utilizes through-hole straight termination and brass contacts plated with gold. Rated for 3 A current and 1500 V insulation voltage, it operates within a temperature range of -55 °C to +105 °C. The housing is black thermoplastic plastic with UL 94 V-0 flammability rating.
Feature Summary
- Vertical board-to-board interconnection capability
- Gold-plated brass contacts for reliable conductivity
- Thermoplastic housing with UL 94 V-0 flame retardancy
Applications
- General electronic equipment interconnects
- Industrial control systems
- Consumer electronics assemblies
Procurement Notes
Verify the complete part number including the suffix BLF to ensure correct material and plating specifications. Confirm that the 12-position, 2-row configuration matches the target PCB footprint. Check for RoHS compliance status if required by specific regional regulations or end-product standards before finalizing procurement orders.
Selection Notes
Select this component when vertical mounting is required for low-profile board stacking. The 2.54 mm pitch ensures compatibility with standard PCB spacing. Ensure the application environment stays within the specified -55 °C to +105 °C operating range. Verify that the 3 A current rating meets the circuit requirements without excessive heating.
Part Context
This part belongs to the Amphenol EconoStik series, which focuses on cost-effective connectivity solutions. The series offers various contact counts and row configurations while maintaining consistent 2.54 mm pitch dimensions. It serves as a standard header solution for mass-produced electronic devices requiring reliable through-hole assembly.
Replacement Considerations
Compatible substitutes include other 12-pin, 2-row headers with 2.54 mm pitch from the same manufacturer series. Cross-referencing mechanical dimensions and electrical ratings is essential when considering alternative suppliers.
