Product Detailed Parameters
- Description：CONN HEADER R/A 6POS 2.54MM
- Series：EconoStik™ 10129382
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：6
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.230" (5.84mm)
- Contact Length - Post：0.120" (3.05mm)
- Overall Contact Length：-
- Insulation Height：-
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) EconoStik header is a through-hole, right-angle pin strip connector with 50 positions in a dual-row configuration. It features a 2.54 mm pitch and row spacing, utilizing brass contacts with gold plating for reliable signal transmission. The housing is constructed from black thermoplastic material rated UL 94 V-0 for flame resistance. Designed for board-to-board applications, it supports a current rating of 3 A and operates within a temperature range of -55°C to +105°C.
Feature Summary
- EconoStik series design supporting up to 50 mating cycles
- Right-angle through-hole termination for space-efficient mounting
- Gold-plated brass contacts ensuring corrosion resistance
- Thermoplastic insulation with UL 94 V-0 flammability rating
Applications
- Industrial control systems
- Test equipment interfaces
- General-purpose board-to-board connections
Procurement Notes
Verify the specific ordering suffix against the manufacturer's official documentation to ensure correct contact length and housing color specifications. Confirm that the component meets RoHS compliance requirements if applicable to your assembly process. Cross-reference the datasheet for precise mechanical dimensions to validate PCB footprint compatibility before finalizing procurement orders.
Selection Notes
Select this component when a low-cost, high-density interconnect solution is required for industrial environments. The EconoStik series offers a balance of performance and economy suitable for general-purpose applications. Ensure the selected variant matches the required stacking height and mating cycle expectations for the target system design.
Part Context
This part belongs to the Amphenol FCI EconoStik family, which provides cost-effective interconnect solutions for various electronic markets. The brand, now integrated into Amphenol ICC, leverages extensive experience in high-performance interconnect systems. This specific model represents a standard pin header option within their broad portfolio of board-to-board connectors.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation.
