Product Detailed Parameters
- Description：CONN HEADER R/A 6POS 2.54MM
- Series：EconoStik™ 10129382
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：6
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：0.090" (2.29mm)
- Overall Contact Length：-
- Insulation Height：-
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) 10129382-906004BLF is a right-angle header connector from the EconoStik series. It features a 6-position, single-row layout with a 2.54mm pitch. The connector utilizes through-hole termination and gold-plated brass contacts. Rated for 3A current and 110VDC voltage, it operates within a temperature range of -55°C to +105°C. The housing is black thermoplastic with UL94 V-0 flammability rating.
Feature Summary
- Supports up to 50 mating cycles for reliable board-to-board connections
- EconoStik design ensures secure pin retention and stability
- Gold contact plating provides corrosion resistance and low contact impedance
Applications
- Industrial control systems
- Test equipment interfaces
- Medical device assemblies
- Telecommunications hardware
Procurement Notes
Verify the specific part number against official Amphenol ICC documentation to confirm pin count, pitch, and termination style. Ensure compatibility with mating sockets regarding height and locking mechanisms. Check for RoHS compliance status if required by project specifications. Confirm availability as this may be a special order item.
Selection Notes
Select this component for applications requiring robust board-to-board interconnects with moderate cycle life. The 2.54mm pitch is standard for general-purpose electronics. Consider the right-angle form factor for space-constrained PCB layouts. Verify that the 3A current rating meets the circuit requirements.
Part Context
This connector belongs to the EconoStik family, designed for cost-effective and reliable interconnect solutions. Amphenol ICC acquired FCI, integrating their connector technologies into the broader portfolio. This series targets industrial and commercial markets needing durable rectangular headers.
Replacement Considerations
Compatible replacements must match the 6-position count, 2.54mm pitch, and right-angle through-hole configuration. Verify that alternative headers support similar current ratings and operating temperatures. Ensure mechanical dimensions align with existing PCB footprints and mating constraints.
