Product Detailed Parameters
- Description：CONN HEADER R/A 8POS 2.54MM
- Series：EconoStik™ 10129382
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：8
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.230" (5.84mm)
- Contact Length - Post：0.090" (2.29mm)
- Overall Contact Length：-
- Insulation Height：-
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) part number 10129382-908002BLF is a rectangular connector header featuring 8 positions arranged in a dual row. It utilizes a 2.54mm pitch and employs right-angle through-hole termination for secure board mounting. The contacts are constructed from copper alloy with brass variants noted, rated for a maximum current of 3A. Operating temperature ranges up to +105°C. The housing is black, UL94 V-0 rated, and supplied in bulk packaging.
Feature Summary
- Right-angle through-hole design for efficient PCB space utilization
- Dual-row configuration supporting compact signal routing
- Black UL94 V-0 flammability rated insulator material
Applications
- General electronic equipment interconnections
- Industrial control system circuit boards
- Consumer electronics internal wiring
Procurement Notes
Verify the specific contact material composition, as sources indicate both copper alloy and brass. Confirm the exact plating specification against the official datasheet to ensure compatibility with mating connectors. Check for any recent PCN updates regarding material changes or manufacturing site transfers before finalizing procurement orders.
Selection Notes
Select this component when a low-profile, right-angle header is required for 2.54mm pitch applications. Ensure the 3A current rating meets the circuit requirements. Consider the bulk packaging format for high-volume assembly processes where individual tape handling is not necessary.
Part Context
This connector belongs to the standard rectangular header family produced by Amphenol ICC (FCI). It serves as a fundamental interconnect solution for board-to-wire or board-to-board connections in commercial and industrial electronics, providing reliable electrical pathways within constrained spatial environments.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify mechanical footprint and pinout compatibility if considering alternative manufacturers' equivalents.
