10129382-910001BLF

Overview

The Amphenol ICC (FCI) 10129382-910001BLF is a header connector from the EconoStik series. It features 10 positions with a 2.54 mm pitch and two rows. The component utilizes through-hole right-angle termination for secure board mounting. Contact surfaces are gold-plated brass pins rated for 3 A current. The housing is black thermoplastic with UL 94 V-0 flammability classification. Operating temperature ranges from -55°C to +105°C.

Feature Summary

• Right-angle through-hole mounting design
• Gold-plated brass contact pins
• Black thermoplastic housing material

Applications

• Board-to-board interconnections
• Industrial equipment systems
• Medical device assemblies
• Telecommunications infrastructure

Procurement Notes

Verify RoHS3 compatibility status directly with the manufacturer or authorized distributors, as environmental compliance data may vary by production batch. Confirm that the specific ordering suffix matches the required pin count and row configuration. Request official datasheets to validate mechanical dimensions and thermal ratings before integration into final designs.

Selection Notes

Select this component for applications requiring right-angle signal routing on printed circuit boards. The 2.54 mm pitch ensures compatibility with standard wire harnesses and mating headers. Consider the 3 A current rating and operating temperature range when designing for high-power or extreme environment scenarios within industrial or medical sectors.

Part Context

This part belongs to the EconoStik family of connectors manufactured by Amphenol ICC (FCI). The series is designed for general-purpose electronic interconnects. The specific model provides a reliable solution for low-to-medium density board connections in commercial and industrial electronics.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
