Product Detailed Parameters
- Description：CONN HEADER R/A 10POS 2.54MM
- Series：EconoStik™ 10129382
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：10
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.230" (5.84mm)
- Contact Length - Post：0.090" (2.29mm)
- Overall Contact Length：-
- Insulation Height：-
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) part number 10129382-910002BLF is a right-angle pin header connector belonging to the EconoStik series. It features a 2.54 mm pitch and accommodates 10 contacts arranged in a double-row configuration. The component utilizes through-hole termination for secure board mounting. Electrical specifications include a rated current of 3 A and an insulation resistance of 1 GOhm. The design incorporates unlatched retention, ensuring direct mechanical engagement without additional locking hardware.
Feature Summary
- Right-angle orientation facilitates compact vertical board-to-board interconnections
- Through-hole termination provides robust mechanical stability on printed circuit boards
- Unlatched design simplifies assembly processes for standard stacking applications
Applications
- Board-to-board interconnection systems
- Compact electronic device assemblies requiring vertical spacing
- General-purpose industrial control modules
Procurement Notes
Verify the specific suffix BLF against official manufacturer documentation to confirm material composition and compliance status. Ensure that procurement channels source directly from authorized distributors to guarantee authenticity. Cross-reference the full part number with the latest datasheet revisions to confirm availability of updated environmental certifications before finalizing purchase orders.
Selection Notes
Select this component when a low-profile, right-angle connection is required between parallel circuit boards. The 2.54 mm pitch offers compatibility with standard PCB footprints. Consider the unlatched nature for applications where mating force is managed by structural housing rather than connector latches. Evaluate space constraints to ensure the right-angle profile fits within the designated enclosure volume.
Part Context
This connector belongs to the EconoStik family, which focuses on cost-effective interconnect solutions. The series is characterized by standardized dimensions and reliable performance for general electronics. The 10129382 variant specifically addresses needs for small-form-factor connections where space efficiency is prioritized over high-density pin counts.
