Product Detailed Parameters
- Description：CONN HEADER R/A 10POS 2.54MM
- Series：EconoStik™ 10129382
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：10
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：0.120" (3.05mm)
- Overall Contact Length：-
- Insulation Height：-
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) part number 10129382-910003BLF is a header connector from the EconoStik series. It features a 10-position configuration with two rows, utilizing a 2.54 mm pitch. The connector is designed for right-angle through-hole mounting and employs male pin contacts. The housing is black thermoplastic, and the unit is rated for operation between -55°C and +105°C.
Feature Summary
- Right-angle orientation facilitates compact board-to-board connections.
- Through-hole termination ensures secure mechanical attachment to the PCB.
- EconoStik series design provides reliable signal integrity.
Applications
- Board-to-board interconnects
- General electronic equipment
- Industrial control systems
Procurement Notes
Verify the specific suffix against official manufacturer documentation to confirm exact contact plating and material specifications. Ensure that the right-angle orientation matches the target PCB layout requirements before finalizing procurement orders.
Selection Notes
Select this component when a low-profile, right-angle header is required for dense circuit layouts. Confirm that the 2.54 mm pitch aligns with existing board patterns and that the through-hole mounting style is compatible with the assembly process.
Part Context
This connector belongs to the EconoStik family produced by Amphenol ICC (FCI). The series is engineered for cost-effective connectivity solutions in commercial electronics, offering standard pin configurations suitable for general-purpose signal transmission applications.
Replacement Considerations
Cross-reference with other 10-position, 2-row, 2.54mm pitch right-angle headers from the same manufacturer series to ensure mechanical and electrical compatibility before substitution.
