10129382-910004BLF

Overview

The 10129382-910004BLF is a right-angle header connector from the EconoStik series by Amphenol ICC (FCI). It features a 2.54 mm pitch and a 10-position, single-row configuration with male pin contacts. Designed for through-hole termination, this black thermoplastic component supports board-to-board connections. The contacts are gold-plated to ensure reliable signal transmission. It operates within a temperature range of -55°C to +105°C and carries a UL 94 V-0 flammability rating.

Feature Summary

• Supports up to 50 mating cycles for durable repeated use
• Right-angle design facilitates efficient board-to-board spatial arrangement
• Gold contact plating ensures reliable electrical performance

Applications

• Industrial control systems
• Test equipment interconnections

Procurement Notes

Verify the specific part number against official Amphenol documentation to confirm current availability status. As a discontinued or limited-stock item, lead times may vary significantly. Ensure compatibility with mating receptacles regarding pitch and row count before procurement.

Selection Notes

Select this component when a low-profile, right-angle through-hole header is required for industrial applications. The 2.54 mm pitch matches standard DIP spacing. Consider the 50-cycle mating limit for maintenance-heavy environments. Verify that the single-row format fits the PCB layout constraints.

Part Context

This connector belongs to the EconoStik family, which provides cost-effective solutions for general-purpose interconnect needs. The series is characterized by its robust thermoplastic housing and standardized 2.54 mm spacing, widely used in commercial and industrial electronics for stable board connections.

Replacement Considerations

Direct substitutes include other 10-position, 2.54 mm pitch right-angle headers from the same manufacturer. Cross-reference with generic equivalents only if mechanical dimensions and contact plating specifications match exactly.
