Product Detailed Parameters
- Description：CONN HEADER R/A 12POS 2.54MM
- Series：EconoStik™ 10129382
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：12
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：0.120" (3.05mm)
- Overall Contact Length：-
- Insulation Height：-
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) part number 10129382-912003BLF is a pin header connector belonging to the EconoStik series. It features a 2x6 configuration, providing 12 positions with a 2.54 mm pitch. The connector utilizes right-angle through-hole mounting for board-to-board applications. Electrical specifications include a current rating of 3 A and an insulation voltage of 1500 V. The operating temperature range spans from -55°C to +105°C. Contact materials consist of brass with gold plating, while the housing is constructed from black thermoplastic plastic rated UL 94 V-0.
Feature Summary
- Right-angle through-hole design facilitates compact vertical integration in dense circuit layouts.
- Gold-plated brass contacts ensure reliable signal transmission and corrosion resistance.
- Thermoplastic housing provides mechanical stability and meets UL 94 V-0 flammability standards.
Applications
- Board-to-board interconnections
- Industrial control systems
- Consumer electronics assemblies
Procurement Notes
Verify the specific suffix 'BLF' against official Amphenol documentation to confirm lead-free compliance and material composition. Ensure the right-angle orientation matches the target PCB footprint requirements. Cross-reference the 12-position count to avoid confusion with similar series variants that may differ in row or contact quantity.
Selection Notes
Select this component when a low-profile, cost-effective solution is required for rigid board connections. The 2.54 mm pitch ensures compatibility with standard manufacturing processes. Consider the 3 A current rating for power distribution needs within the specified thermal environment. Verify that the right-angle form factor aligns with spatial constraints and mating connector heights.
Part Context
This component is part of the EconoStik family produced by Amphenol ICC (formerly FCI). The series is designed for general-purpose electronic interconnects, emphasizing reliability and ease of assembly. Amphenol acquired FCI to expand its portfolio in information and communication markets, integrating advanced plating and signal integrity technologies into these standard header solutions.
Replacement Considerations
Direct substitutes must match the 2x6 pin count, 2.54 mm pitch, right-angle orientation, and through-hole termination method. Verify that alternative parts maintain equivalent current ratings and insulation voltage levels. Check for compatible housing materials and flammability ratings to ensure environmental resilience.
