Product Detailed Parameters
- Description：CONN HEADER R/A 12POS 2.54MM
- Series：EconoStik™ 10129382
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：12
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：0.090" (2.29mm)
- Overall Contact Length：-
- Insulation Height：-
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) 10129382-912004BLF is a pin header connector from the Econostik series. It features a 2-row configuration with 12 positions and a 2.54 mm pitch. Designed for right-angle through-hole mounting, it utilizes gold-plated brass contacts rated for 3 A current. The housing is black thermoplastic with UL 94 V-0 flammability. Operating temperature ranges from -55°C to +105°C.
Feature Summary
- Right-angle through-hole mounting for board-to-board connections
- Gold-plated brass contacts ensuring reliable signal integrity
- EconoStik series design for standard industrial applications
Applications
- Board-to-board interconnections
- General electronic equipment
- Industrial control systems
Procurement Notes
Verify the specific manufacturer part number against official Amphenol documentation to confirm availability and lead times. Ensure that the right-angle orientation and 2.54 mm pitch match the target PCB layout requirements before procurement.
Selection Notes
Select this component when a low-profile, right-angle header is required for 12-position interfaces. The 2.54 mm pitch aligns with standard grid spacing, while the Econostik series offers cost-effective solutions for general-purpose connectivity needs.
Part Context
This connector belongs to the Amphenol FCI Econostik family, which provides versatile interconnect solutions for commercial electronics. The brand transition from FCI to Amphenol ICC maintains product lineage while integrating broader global manufacturing capabilities.
Replacement Considerations
Compatible alternatives include other 12-position, 2.54 mm pitch headers from the same series or equivalent third-party manufacturers offering identical mechanical dimensions and electrical ratings.
