10129382-920001BLF

Overview

The Amphenol ICC (FCI) 10129382-920001BLF is a header connector from the EconoStik series. It features 20 positions arranged in two rows with a 2.54 mm pitch. The connector utilizes through-hole termination and right-angle mounting. Contacts are gold-plated brass pins designed for board-to-board applications. The housing is black thermoplastic rated UL94 V-0, supporting operation between -55°C and +105°C.

Feature Summary

• EconoStik series design for reliable board-to-board interconnection
• Right-angle through-hole mounting for space-constrained layouts
• Gold-plated brass contacts ensure stable signal transmission
• Thermoplastic housing provides UL94 V-0 flame retardancy

Applications

• Board-to-board interconnects
• Industrial instrumentation systems
• Factory automation equipment
• IoT device circuitry

Procurement Notes

Verify component authenticity against official Amphenol documentation. Confirm that the specific suffix matches the required pin count and orientation. Ensure storage conditions maintain moisture sensitivity level integrity prior to soldering. Cross-reference datasheet revisions to confirm material specifications align with current manufacturing standards.

Selection Notes

Select this model when right-angle through-hole headers are required for 2.54 mm pitch applications. The dual-row configuration supports higher density than single-row alternatives. Verify that the 3 A current rating meets system requirements. Consider the operating temperature range for environmental compatibility.

Part Context

This component belongs to the EconoStik family of connectors manufactured by Amphenol ICC (FCI). The series focuses on cost-effective solutions for general-purpose electronic interconnections. The manufacturer integrates FCI technology into its communications solutions portfolio.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
