10129383-904002ALF

Overview

The 10129383-904002ALF is a surface mount header connector manufactured by Amphenol ICC (FCI). It features a single row with four positions and a pitch of 0.100 inches (2.54mm). The connector utilizes gold plating on the contact surfaces to ensure reliable signal transmission. Designed for PCB mounting, it supports automated assembly processes through its surface mount configuration.

Feature Summary

• Surface mount design facilitates automated PCB assembly
• Gold-plated contacts provide corrosion resistance
• Single row configuration with four positions

Applications

• General electronic interconnects
• Consumer electronics assemblies
• Industrial control boards

Procurement Notes

Verify the specific ordering suffix to confirm lead-free status and RoHS compliance. Ensure the package type matches the required surface mount footprint. Confirm that the pin count and pitch align with the target PCB layout before procurement.

Selection Notes

Select this component when a low-profile, surface mount header is required for board-to-board or cable connections. Consider the 2.54mm pitch compatibility with standard connectors. Evaluate the mechanical stability provided by the surface mount termination for vibration environments.

Part Context

This part belongs to the Amphenol ICC (FCI) header connector portfolio. It represents a standard interconnect solution within their surface mount product line. The manufacturer provides engineering support for integration into various electronic systems requiring reliable electrical pathways.

Replacement Considerations

Check for direct cross-reference part numbers from Amphenol or other major distributors. Verify that any substitute maintains the same 2.54mm pitch and four-position configuration. Ensure mechanical dimensions and soldering profiles are compatible with existing manufacturing processes.
