10129383-906002ALF

Overview

The Amphenol ICC (FCI) part number 10129383-906002ALF is a surface mount header connector belonging to the Econostik series. It features a 2x3 contact configuration with a 2.54 mm pitch. The unit utilizes gold GXT™ plating on the contacts, providing a current rating of 3A and a voltage rating of 110VDC. Designed for vertical through-hole or surface mount termination, this black-insulated component serves as a board-to-board interconnect solution.

Feature Summary

• Econostik series design optimized for general purpose electronic applications
• Gold GXT™ contact plating ensures reliable signal transmission and corrosion resistance
• Vertical surface mount orientation facilitates compact PCB layout integration

Applications

• Industrial control systems requiring robust board-to-board connections
• Medical equipment utilizing low-voltage signal interconnects
• Telecommunications infrastructure components
• General purpose consumer electronics assemblies

Procurement Notes

Verify the specific suffix 'ALF' against official manufacturer documentation to confirm lead-free compliance status and exact material specifications. Ensure the selected variant matches the required surface mount orientation and pin count for your circuit design. Cross-reference the base product number 10129383 for any applicable engineering change notices or material updates prior to final procurement decisions.

Selection Notes

Select this component when a 2-row, 6-position header with 2.54 mm spacing is required for surface mount assembly. Confirm that the 3A current and 110VDC voltage ratings align with the target application's electrical requirements. Consider the black insulation color and vertical profile constraints during mechanical design integration to ensure proper clearance and mating compatibility.

Part Context

This connector belongs to the Amphenol ICC (FCI) Econostik family, which provides cost-effective connectivity solutions for various electronic markets. The brand operates under Amphenol ICC, leveraging extensive experience in signal integrity and power management. This specific model represents a standard high-volume interconnect option within their broader portfolio of headers and wire housings.

Replacement Considerations

Consult official cross-reference data for direct substitutes. Verify that any alternative maintains identical 2.54 mm pitch, 2x3 configuration, and surface mount termination style to ensure mechanical fit.
