Product Detailed Parameters
- Description：CONN HEADER SMD 8POS 2.54MM
- Series：EconoStik™ 10129383
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：8
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) part number 10129383-908002BLF is a surface-mount header connector from the EconoStik™ series. It features an 8-position, single-row configuration with a 2.54mm pitch. The contacts are male pins with a black insulation color. Rated for 3A current and 110VDC voltage, it utilizes a push-pull fastening mechanism. Designed for board-to-board applications, it supports up to 50 mating cycles.
Feature Summary
- Supports up to 50 mating cycles for reliable repeated connections
- Utilizes a push-pull fastening mechanism for secure attachment
- Features male pin contact type for board-to-board interfacing
Applications
- Industrial control systems
- Test equipment interfaces
- Medical device assemblies
- Telecommunications hardware
Procurement Notes
Verify component authenticity by checking manufacturer markings against official datasheets. Confirm RoHS compliance status as indicated in product documentation. Ensure storage conditions maintain integrity prior to assembly. Cross-reference ordering suffixes to confirm exact variant specifications before procurement.
Selection Notes
Select this component for applications requiring robust board-to-board connectivity with limited mating cycle requirements. The 2.54mm pitch suits standard PCB layouts. Consider the push-pull feature for secure mechanical retention. Verify voltage and current ratings align with system electrical demands.
Part Context
This connector belongs to the EconoStik™ series by Amphenol ICC (FCI), formerly FCI. The series provides cost-effective interconnect solutions for various electronic assemblies. Amphenol acquired FCI, continuing the brand's legacy in reliable connector manufacturing for diverse industrial sectors.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Consult manufacturer engineering resources for potential cross-references or updated equivalents if this specific part is unavailable.
