Product Detailed Parameters
- Description：CONN HEADER SMD 12POS 2.54MM
- Series：EconoStik™ 10129383
- Mfr：Amphenol ICC (FCI)
- Package：Tape & Reel (TR),Cut Tape (CT)
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：12
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：Pick and Place
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The 10129383-912002ALF is a board-to-board connector header manufactured by Amphenol ICC (FCI). It features a 2.54 mm pitch and a 12-position configuration arranged in two rows. Designed for surface mount installation, the component utilizes straight termination to secure connections on printed circuit boards. The Econostik series provides reliable interconnectivity for electronic assemblies requiring precise alignment and stable signal transmission.
Feature Summary
- Surface mount design with straight termination
- Dual-row 12-position layout
- 2.54 mm contact spacing
Applications
- Board-to-board interconnections
- Electronic assembly integration
- Signal transmission circuits
Procurement Notes
Verify the manufacturer part number against official Amphenol ICC documentation to ensure compatibility. Confirm that the surface mount package type matches the target PCB footprint requirements. Check for RoHS compliance status if environmental regulations apply to the specific project scope.
Selection Notes
Select this component when a low-profile, dual-row header is required for direct board stacking or connection. Ensure the 2.54 mm pitch aligns with existing system design constraints. Verify that the straight orientation fits within the available vertical clearance of the enclosure.
Part Context
This part belongs to the Econostik series from Amphenol ICC (FCI), which focuses on cost-effective and reliable connectivity solutions. The series supports various configurations for general-purpose electronic applications, providing standardized interfaces for modern manufacturing processes.
Replacement Considerations
Check for alternative part numbers within the same Econostik family that offer different pin counts or row configurations. Verify mechanical compatibility before substituting with similar headers from other manufacturers.
