Product Detailed Parameters
- Description：CONN HEADER SMD 14POS 2.54MM
- Series：EconoStik™ 10129383
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：14
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.230" (5.84mm)
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) part number 10129383-914001BLF is a surface mount header connector featuring 14 positions with a 0.100 inch (2.54mm) pitch. Designed for vertical board-to-board applications, it utilizes a single row configuration and offers tin plating on the contacts to ensure reliable electrical conductivity. The component is engineered for automated assembly processes due to its surface mount technology compatibility.
Feature Summary
- Surface mount design facilitates automated pick-and-place manufacturing
- Single row header configuration provides compact footprint
- Tin contact plating ensures corrosion resistance and solderability
Applications
- Server backplane interconnects
- Industrial control system circuit boards
- Telecommunications equipment signal routing
Procurement Notes
Verify the specific suffix 'BLF' against the manufacturer's current datasheet to confirm compliance with lead-free and halogen-free requirements. Ensure that the surface mount termination style matches the PCB pad layout. Confirm availability status as distribution channels may list obsolete or end-of-life inventory for this series.
Selection Notes
Select this component when a low-profile, single-row header is required for high-density signal routing. The 2.54mm pitch is standard for general-purpose digital signals. Consider thermal management during reflow soldering due to the surface mount construction. Validate mechanical retention needs as this variant lacks integrated locking features.
Part Context
This connector belongs to the EconoStik family of board-to-board interconnect solutions. It represents a cost-effective option for mass-produced electronics where space constraints are moderate. The product line focuses on providing reliable connections for consumer and industrial devices without complex locking mechanisms.
Replacement Considerations
Direct substitutes include other 14-position, 2.54mm pitch surface mount headers from Amphenol or compatible manufacturers such as Molex or Samtec. Verify identical pin count, pitch, and mounting orientation before substitution.
