10129383-916001ALF

$0.44

Description：CONN HEADER SMD 16POS 2.54MM
Series：EconoStik™ 10129383
Mfr：Amphenol ICC (FCI)
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:5012184d6a9a Category: Headers, Male Pins Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HEADER SMD 16POS 2.54MM
Series：EconoStik™ 10129383
Mfr：Amphenol ICC (FCI)
Package：Tape & Reel (TR),Cut Tape (CT)
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：16
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.230" (5.84mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：1.00µin (0.025µm)
Contact Finish - Post：-
Contact Material：Copper Alloy
Insulation Material：Thermoplastic
Features：Pick and Place
Operating Temperature：-55°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：110VDC

Download product information

10129383-916001ALF

Overview

The Amphenol ICC (FCI) part number 10129383-916001ALF is a surface mount board-to-board header connector. It features a 2.54 mm pitch and contains 16 contacts arranged in two rows. The connector utilizes copper alloy contacts with gold plating for reliable signal transmission. Designed for pick-and-place assembly, it supports standard SMD manufacturing processes. The unit operates within a temperature range of -55°C to 105°C and meets UL94 V-0 flammability standards.

Feature Summary

Dual-row surface mount configuration for high-density board-to-board interconnects
Gold-plated copper alloy contacts ensuring stable electrical performance
Optimized for automated pick-and-place assembly workflows

Applications

Industrial control systems
Test equipment interfaces

Procurement Notes

Verify the specific contact count and row configuration against the official datasheet before integration. Confirm that the operating temperature range aligns with the target environment requirements. Ensure compatibility with standard reflow soldering profiles for surface mount technology. Cross-reference the material flammability rating if safety compliance is critical for the final product design.

Selection Notes

Select this component when a dual-row 2.54 mm pitch header is required for surface mount applications. The gold plating offers superior conductivity compared to tin alternatives. Consider the physical dimensions and mating height constraints during PCB layout. Verify that the mechanical locking mechanism suits the assembly stress conditions.

Part Context

This component belongs to the EconoStik series by Amphenol ICC (FCI). The series provides robust rectangular connectors designed for various electronic markets. These connectors are engineered to support up to 50 mating cycles, offering durability for repeated connection scenarios. The series emphasizes cost-effective solutions without compromising on signal integrity or mechanical reliability.
