10129383-916001BLF

$0.35

Description：CONN HEADER SMD 16POS 2.54MM
Series：EconoStik™ 10129383
Mfr：Amphenol ICC (FCI)
Package：Bulk

SKU:d38809fe031e Category: Headers, Male Pins Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HEADER SMD 16POS 2.54MM
Series：EconoStik™ 10129383
Mfr：Amphenol ICC (FCI)
Package：Bulk
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：16
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.230" (5.84mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：1.00µin (0.025µm)
Contact Finish - Post：-
Contact Material：Copper Alloy
Insulation Material：Thermoplastic
Features：-
Operating Temperature：-55°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：110VDC

Download product information

10129383-916001BLF

Overview

The Amphenol ICC (FCI) part number 10129383-916001BLF is a surface mount header connector belonging to the Minitek product family. It features a 16-position configuration with a 2.54mm pitch and two rows of contacts. The connector utilizes brass contact materials with a gold plating finish to ensure reliable signal transmission. Designed for board-to-board applications, it supports pick-and-place assembly processes. The unit operates within a temperature range of -55°C to +105°C and meets RoHS compliance standards.

Feature Summary

Surface mount design facilitates automated pick-and-place manufacturing processes
Gold-plated brass contacts provide durable electrical connectivity
Two-row header configuration optimizes space on printed circuit boards

Applications

Board-to-board interconnections in electronic assemblies
Signal routing in compact consumer electronics devices
Industrial control system circuitry integration

Procurement Notes

Verify the specific suffix BLF against official manufacturer documentation to confirm exact pin count and plating specifications. Ensure compatibility with standard surface mount reflow soldering profiles. Confirm that the selected variant matches the required 2.54mm pitch and 16-position layout for your specific PCB footprint design requirements.

Selection Notes

Select this component when a low-profile, surface-mount header is required for high-density signal routing. The 2.54mm pitch offers a balance between spacing and density suitable for general-purpose electronics. Consider the operating temperature range and RoHS compliance if the application involves strict environmental or regulatory constraints.

Part Context

This connector belongs to the Minitek series by Amphenol ICC (FCI), a brand known for providing innovative interconnect solutions for information and communication markets. The Minitek line focuses on signal integrity and efficient power management, catering to the growing demands of commercial electronic equipment and data processing systems.
