10129383-918001ALF

Overview

The Amphenol ICC (FCI) part number 10129383-918001ALF is a surface mount header connector designed for general-purpose electronic applications. It features a 2.54mm pitch and provides 18 positions in a single row configuration. The connector utilizes gold-plated copper alloy contacts to ensure reliable signal transmission and low contact resistance. Rated for a current of 3A and a voltage of 110VDC, it operates within a temperature range of -55°C to 105°C. The housing is constructed from thermoplastic material with a black insulation color, offering UL94 V-0 flammability rating. This component supports automated pick-and-place assembly processes.

Feature Summary

• Surface mount termination facilitates automated pick-and-place manufacturing integration.
• Gold-plated copper alloy contacts provide durable electrical connectivity.
• Thermoplastic housing ensures structural integrity and flame resistance.

Applications

• General purpose electronics
• Industrial equipment
• Medical devices
• Telecommunications systems

Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to confirm pin count, pitch, and termination style match the design requirements. Ensure the selected variant aligns with the required operating temperature range and current ratings. Cross-reference the RoHS compliance status and material specifications with the latest datasheet to guarantee regulatory adherence for the intended application environment.

Selection Notes

Select this connector when a 2.54mm pitch surface mount header is required for board-to-board or cable-to-board connections. Consider the 18-position count and 3A current rating suitability for the circuit load. Evaluate the -55°C to 105°C operating range against environmental conditions. Confirm that the black thermoplastic housing meets aesthetic and flammability standards for the final product assembly.

Part Context

This component belongs to the standard rectangular connector family manufactured by Amphenol ICC (FCI). It is part of a broader portfolio of interconnect solutions supporting various industrial and commercial markets. The series offers consistent dimensional tolerances and mating compatibility within its designated pitch class, ensuring reliable performance across diverse electronic assemblies.

Replacement Considerations

Consult the manufacturer's official cross-reference guide for verified substitute part numbers. Ensure any replacement maintains identical 2.54mm pitch, 18-position count, and surface mount termination type. Verify that alternative components meet the same 3A current and 110VDC voltage ratings without compromising thermal or mechanical performance.

FAQ

What is the rated current for this connector?

The connector has a rated current capacity of 3A.

Is this connector suitable for high-temperature environments?

Yes, it operates within a temperature range of -55°C to 105°C.
