Product Detailed Parameters
- Description：CONN HEADER SMD 18POS 2.54MM
- Series：EconoStik™ 10129383
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：18
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) part number 10129383-918002BLF is a surface-mount header connector featuring 18 positions arranged in a dual-row configuration. It utilizes a 2.54 mm pitch and is designed for vertical orientation on printed circuit boards. The component supports a current rating of 3A and operates at a voltage rating of 110VDC. Packaged in bulk, this connector serves as a reliable interface solution for electronic assemblies requiring high-density board-to-board or wire-to-board connections.
Feature Summary
- Surface-mount technology design for automated assembly processes
- Dual-row header configuration providing 18 contact positions
- Vertical orientation optimized for standard PCB layouts
Applications
- General-purpose electronic equipment interconnects
- Industrial control system signal routing
- Consumer electronics internal wiring harnesses
Procurement Notes
Verify the specific suffix BLF against official manufacturer documentation to confirm material composition and plating specifications. Ensure that the bulk packaging format aligns with your manufacturing line requirements. Cross-reference the 18-position count and 2.54mm pitch with your schematic designs to guarantee mechanical compatibility before initiating purchase orders.
Selection Notes
Select this component when a vertical, surface-mount header with a 2.54mm pitch is required for 18-channel applications. Consider the 3A current rating and 110VDC voltage limit during electrical design validation. Evaluate the bulk packaging option against your reflow soldering capabilities and inventory handling procedures to ensure efficient production integration.
Part Context
This connector belongs to the EconoStik series by Amphenol ICC (FCI), formerly known as FCI. The series focuses on cost-effective connectivity solutions for information, communication, and commercial electronic markets. Amphenol acquired FCI in 2016, integrating its extensive portfolio into the Amphenol ICC division to support global electronics manufacturing needs.
Replacement Considerations
Compatible substitutes include the 10129383-912003BLF variant, which offers a similar 2.54mm pitch but features 12 positions instead of 18. When replacing, verify that the reduced pin count meets the circuit requirements and that the surface-mount footprint remains identical to avoid PCB redesign.
