Product Detailed Parameters
- Description：CONN PWR4.2 HCC TERM
- Series：*
- Mfr：Amphenol ICC (FCI)
- Package：Tape & Reel (TR),Cut Tape (CT)
- Connector Type：-
- Contact Type：-
- Pitch - Mating：-
- Number of Positions：-
- Number of Rows：-
- Row Spacing - Mating：-
- Number of Positions Loaded：-
- Style：-
- Shrouding：-
- Mounting Type：-
- Termination：-
- Fastening Type：-
- Contact Length - Mating：-
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：-
- Contact Shape：-
- Contact Finish - Mating：-
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：-
- Contact Material：-
- Insulation Material：-
- Features：-
- Operating Temperature：-
- Ingress Protection：-
- Material Flammability Rating：-
- Insulation Color：-
- Current Rating (Amps)：-
- Voltage Rating：-
Download product information
Overview
The 10130517-121LF is a Minitek Pwr 4.2 header terminal manufactured by Amphenol ICC (FCI). It is designed for high-current applications within the Minitek Power series. The component features a male pin configuration intended for surface mount termination onto printed circuit boards. It utilizes a copper alloy contact material with tin plating to ensure reliable electrical conductivity and corrosion resistance. The connector is part of the Minitek Pwr 4.2 series, which supports higher current ratings compared to standard signal connectors.
Feature Summary
- High-current capability suitable for power distribution in compact electronic systems
- Surface mount design for automated assembly processes
- Tin-plated copper alloy contacts for stable electrical performance
Applications
- Server and storage equipment power distribution
- Telecommunications infrastructure power modules
- Industrial control system power interfaces
Procurement Notes
Verify the specific suffix and packaging configuration when ordering, as Amphenol FCI often offers various reel or tape quantities. Confirm that the tin plating specification meets the environmental requirements of the target application. Ensure compatibility with the corresponding Minitek Pwr 4.2 housing or mating connector before finalizing procurement.
Selection Notes
Select this terminal when high current capacity is required in a surface mount form factor. Compare against other Minitek series options if lower current or different pitch specifications are needed. Ensure the PCB layout accommodates the specific footprint and height requirements of the 10130517-121LF terminal to maintain proper mechanical stability during soldering.
Part Context
This component belongs to the Minitek Pwr 4.2 series, a line of power connectors from Amphenol ICC (FCI) designed for demanding environments. The series is widely used in data center and communication equipment where reliable power delivery is critical. The 10130517-121LF specifically serves as a terminal element within this broader ecosystem of interconnect solutions.
Replacement Considerations
Direct substitutes may include other Minitek Pwr 4.2 terminals from Amphenol with identical pin counts and mounting styles. Cross-referencing with generic high-current SMT headers requires careful verification of current ratings and mechanical dimensions to ensure functional equivalence.
