10131318-08522GRLF

Description：CONN HEADER R/A
Series：Minitek® Pwr 4.2 High Current
Mfr：Amphenol ICC (FCI)
Package：Tape & Reel (TR)

SKU:f195c5ed0441 Category: Headers, Male Pins Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HEADER R/A
Series：Minitek® Pwr 4.2 High Current
Mfr：Amphenol ICC (FCI)
Package：Tape & Reel (TR)
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.165" (4.20mm)
Number of Positions：8
Number of Rows：2
Row Spacing - Mating：0.165" (4.20mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Locking Ramp
Contact Length - Mating：-
Contact Length - Post：0.138" (3.50mm)
Overall Contact Length：-
Insulation Height：0.404" (10.26mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：100.0µin (2.54µm)
Contact Finish - Post：-
Contact Material：Copper Alloy
Insulation Material：Liquid Crystal Polymer (LCP)
Features：Glow Wire Compliant
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：Varies by Wire Gauge
Voltage Rating：600V

Download product information

10131318-08522GRLF

Overview

The Amphenol ICC (FCI) part number 10131318-08522GRLF is a right-angle header connector belonging to the Minitek Power4.2 series. It features a dual-row configuration with 22 positions and a 4.2 mm pitch. The contacts are gold-plated copper, rated for 12.5 A current and 600 VAC voltage. Designed for through-hole solder termination, it operates within a temperature range of -40°C to +105°C and offers an insulation resistance of 1 GOhms.

Feature Summary

Dual-row right-angle header design for compact power distribution
Gold-plated contacts ensure reliable conductivity and corrosion resistance
High current and voltage ratings suitable for demanding power applications

Applications

Server and storage equipment power distribution
Telecommunications infrastructure boards
Industrial control system interconnects

Procurement Notes

Verify the specific suffix 'GRLF' against official Amphenol documentation to confirm plating thickness and material specifications. Ensure compatibility with mating receptacles in terms of row count and pitch. Confirm that the right-angle mounting style aligns with the target PCB layout constraints before finalizing procurement orders.

Selection Notes

Select this component when high-current power delivery is required in space-constrained environments. The 4.2 mm pitch allows for robust trace spacing on printed circuit boards. Verify that the operating temperature range meets the environmental requirements of the end application. Ensure the through-hole soldering process is compatible with the connector's thermal characteristics.

Part Context

This connector is part of the Minitek Power4.2 family from Amphenol FCI, designed for power-to-board applications. The series is known for its durability and ability to handle significant electrical loads. Amphenol acquired FCI, integrating these connectors into their broader portfolio for industrial and commercial electronics markets.
