10131318-16422G0LF

Overview

The Amphenol ICC (FCI) part number 10131318-16422G0LF is a Minitek Pwr 4.2 Higher Current Connector (HCC) header designed for power-dense applications. It features a 4-position, 2-row configuration with a 4.2mm pitch and right-angle mounting. The contacts are copper alloy with 30µin gold plating, rated for 12.5A per contact. Operating temperature ranges from -40°C to +105°C, with a voltage rating of 600VAC/DC.

Feature Summary

• Designed for high current density applications with dedicated HCC architecture
• Right-angle surface mount termination for compact board layout integration
• Robust 30µin gold contact finish ensures reliable conductivity and corrosion resistance

Applications

• Power distribution in dense server architectures
• High-current connections in industrial control systems
• Power delivery interfaces in automotive electronics

Procurement Notes

Verify the specific suffix 'G0LF' against official Amphenol documentation to confirm lead-free status and exact plating thickness specifications. Ensure compatibility with mating receptacles within the Minitek Pwr 4.2 series. Confirm that the right-angle orientation matches the PCB design requirements before finalizing orders.

Selection Notes

Select this component when high current capacity exceeding standard headers is required in a limited footprint. The 4.2mm pitch allows for substantial conductor cross-sections compared to finer pitches. Verify that the 600VAC/DC rating aligns with system voltage requirements and that the right-angle form factor fits within mechanical constraints.

Part Context

This connector belongs to the Minitek Pwr 4.2 family by Amphenol ICC (FCI), engineered specifically for higher current handling than traditional signal connectors. The HCC designation indicates optimized contact geometry for thermal management and current carrying capability, distinguishing it from standard power or signal header lines.

Replacement Considerations

Direct substitutes include other Minitek Pwr 4.2 right-angle headers with identical 4-position, 2-row configurations and matching 4.2mm pitch. Ensure replacement parts maintain the same 30µin gold plating thickness and 12.5A current rating to preserve electrical performance.
