10131318-2221100LF

Overview

The Amphenol ICC (FCI) part number 10131318-2221100LF is a Minitek Pwr 4.2 High Current header connector designed for power-to-board applications. It features a 22-position configuration with male pin contacts and a 4.2 mm pitch. The connector utilizes a right-angle through-hole mounting style with solder termination. Rated for 12.5 A current and 600 VAC voltage, it operates within a temperature range of -40°C to +105°C. The housing is constructed from black Nylon 6.6, while the copper contacts are tin-plated.

Feature Summary

• Supports high-current power distribution with a 12.5 A rating per contact
• Provides secure mechanical connection via right-angle through-hole soldering
• Ensures reliable electrical performance in demanding thermal environments up to 105°C

Applications

• Server and storage equipment power distribution
• Communication infrastructure board connections
• Industrial control system power headers

Procurement Notes

Verify the specific ordering suffix and RoHS compliance status directly with the manufacturer or authorized distributors before procurement. Confirm that the right-angle orientation and 22-position count match the target PCB layout requirements. Ensure the soldering process parameters align with the specified thermal limits to maintain contact integrity and insulation resistance specifications during assembly.

Selection Notes

Select this component when a high-current vertical-to-horizontal transition is required for power delivery. The 4.2 mm pitch accommodates substantial conductor sizes compared to standard signal headers. Consider the right-angle form factor for space-constrained enclosures where board stacking height must be minimized. Validate that the 600 VAC rating meets the system's isolation requirements.

Part Context

This connector belongs to the Minitek Pwr 4.2 series by Amphenol ICC (FCI), a line specialized for robust power interconnects. The series is widely utilized in data center and telecommunications hardware due to its durability and high current capacity. As an FCI product, it adheres to rigorous quality standards for industrial and commercial electronic assemblies.

Replacement Considerations

Direct substitutes include other 22-position, 4.2 mm pitch right-angle headers from the same Minitek Pwr 4.2 family, such as 10131318-1421100LF or 10131318-105210PLF variants with matching pin counts and orientations.
