Product Detailed Parameters
- Description：CONN HEADER R/A 22POS 4.2MM
- Series：Minitek® Pwr 4.2 High Current
- Mfr：Amphenol ICC (FCI)
- Package：Tray
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.165" (4.20mm)
- Number of Positions：22
- Number of Rows：2
- Row Spacing - Mating：0.165" (4.20mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：0.138" (3.50mm)
- Overall Contact Length：-
- Insulation Height：0.404" (10.26mm)
- Contact Shape：Square
- Contact Finish - Mating：Tin
- Contact Finish Thickness - Mating：80.0µin (2.03µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Polyamide (PA66), Nylon 6/6
- Features：Glow Wire Compliant
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Natural
- Current Rating (Amps)：Varies by Wire Gauge
- Voltage Rating：600V
Download product information
Overview
The Amphenol ICC (FCI) part number 10131318-22211G0LF is a Power to the Board connector header designed for through-hole mounting. It features a right-angle configuration with 22 positions and a 4.20mm pitch. The component supports a current rating of 12.5 A and a voltage rating of 600 VAC, suitable for high-power applications.
Feature Summary
- Right-angle through-hole header design
- High current capacity of 12.5 A
- Robust 600 VAC voltage rating
Applications
- Power distribution on main circuit boards
- Industrial equipment power interfaces
- Server and storage system power connections
Procurement Notes
Verify the specific pin count and pitch against the target PCB footprint before ordering. Confirm that the 12.5 A current rating meets the thermal requirements of the application. Ensure the right-angle orientation aligns with the mechanical constraints of the assembly.
Selection Notes
Select this component when a high-current, right-angle connection is required for board-to-board or cable-to-board power delivery. The 4.20mm spacing accommodates substantial conductors. Consider the 600 VAC rating for safety margins in industrial environments.
Part Context
This part belongs to the Minitek Power series by Amphenol ICC (FCI), specialized for power-to-the-board architectures. It complements receptacles and other header variants within the same family, offering standardized spacing and robust contact materials for reliable power transmission.
Replacement Considerations
Direct substitutes include other 22-position, 4.20mm pitch right-angle headers from the same manufacturer series. Verify compatibility with mating receptacles such as the 10131318-02421GPLF or similar Minitek Power components to ensure proper alignment and electrical continuity.
