Product Detailed Parameters
- Description：CONN HEADER VERT 2POS
- Series：Minitek® Pwr 4.2 High Current
- Mfr：Amphenol ICC (FCI)
- Package：Tray
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：-
- Number of Positions：2
- Number of Rows：2
- Row Spacing - Mating：0.165" (4.20mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：0.138" (3.50mm)
- Overall Contact Length：-
- Insulation Height：0.504" (12.80mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Polyamide (PA66), Nylon 6/6
- Features：Glow Wire Compliant
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：Varies by Wire Gauge
- Voltage Rating：600VAC/DC
Download product information
Overview
The Amphenol ICC (FCI) part number 10131319-02121G0LF is a Minitek Pwr 4.2 series connector header designed for power-to-board applications. It features 2 positions with a 4.2 mm pitch and utilizes through-hole vertical mounting. The contacts are gold-plated copper alloy, rated for 12.5 A current at +105°C maximum operating temperature. Insulation resistance is specified at 1 GOhm. The component is packaged in trays and complies with RoHS standards.
Feature Summary
- High-current power delivery capability via Minitek Pwr 4.2 architecture
- Gold-plated contact surfaces ensure reliable conductivity and corrosion resistance
- Vertical through-hole design facilitates secure PCB integration
Applications
- Power distribution modules in industrial equipment
- Server and storage system backplanes
- Telecommunications infrastructure power interfaces
Procurement Notes
Verify the specific suffix 'G0LF' against official Amphenol documentation to confirm plating thickness and lead-free status. Ensure the procurement channel provides valid traceability for this discontinued or limited-stock item. Cross-reference the 4.2mm pitch requirement with mating receptacles to prevent mechanical incompatibility during assembly.
Selection Notes
Select this component when a low-pin-count, high-current vertical header is required. The 4.2mm spacing accommodates substantial conductors. Confirm that the 12.5A rating meets the circuit's thermal requirements. Verify that the through-hole footprint matches the target PCB layout constraints.
Part Context
This connector belongs to the Minitek Pwr 4.2 family, engineered for robust power transmission. It serves as a critical interface between power sources and board-level circuits. The series is characterized by its durability and standardized 4.2mm grid, widely used in demanding electronic environments requiring stable electrical connections.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Direct replacement requires identical pin count, pitch, and mounting style verification.
