10131319-0222100LF

Overview

The Amphenol ICC (FCI) 10131319-0222100LF is a vertical power-to-board header from the MinitekPwr 4.2 series. It features a 2-row, 4-position configuration with a 4.2 mm pitch. The connector utilizes copper alloy contacts with gold plating and polyamide insulation rated UL94 V-0. Designed for through-hole mounting, it supports an operating temperature range of -40°C to +105°C and carries a 12.5 A current rating per contact.

Feature Summary

• High-current power delivery via 4.2 mm pitch design
• Gold-plated copper alloy contacts for reliable conductivity
• Vertical through-hole termination for board integration

Applications

• Industrial power distribution systems
• Factory automation equipment
• Alternative energy generation units

Procurement Notes

Verify component authenticity against official Amphenol documentation due to potential counterfeit risks in the interconnect market. Confirm that the specific ordering suffix matches the required contact plating and insulation material specifications. Ensure compatibility with mating power blades before finalizing procurement orders to prevent interface mismatches.

Selection Notes

Select this component when high current capacity is required in a compact vertical form factor. The 4.2 mm pitch allows for robust power traces while maintaining standard board spacing. Verify that the PCB layout accommodates the through-hole footprint and that the mating blade connectors align with the 4.2 mm grid system.

Part Context

This part belongs to the MinitekPwr 4.2 family, designed for power-to-board applications. It complements other headers in the series by offering varied pin counts while maintaining consistent mechanical and electrical characteristics. The series supports industrial environments requiring durable power connections.

Replacement Considerations

No public confirmed substitute part numbers are available for direct replacement.
