Product Detailed Parameters
- Description：CONN HEADER VERT 6POS 4.2MM
- Series：Minitek® Pwr 4.2 High Current
- Mfr：Amphenol ICC (FCI)
- Package：Tray
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.165" (4.20mm)
- Number of Positions：6
- Number of Rows：2
- Row Spacing - Mating：0.165" (4.20mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：0.138" (3.50mm)
- Overall Contact Length：-
- Insulation Height：0.504" (12.80mm)
- Contact Shape：Square
- Contact Finish - Mating：Tin
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Polyamide (PA66), Nylon 6/6
- Features：Glow Wire Compliant
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：Varies by Wire Gauge
- Voltage Rating：600VAC/DC
Download product information
Overview
The Amphenol ICC (FCI) part number 10131319-06221G0LF is a Minitek Pwr 4.2 series header connector designed for power-to-board applications. It features a dual-row, vertical through-hole mounting style with a 4.2 mm pitch and six positions. The contacts are gold-plated copper, housed in black liquid crystal polymer (LCP). Rated for 12.5 A current and 600 VAC voltage, it operates within a temperature range of -40°C to +105°C and offers 1 GOhm insulation resistance.
Feature Summary
- High-current capability rated at 12.5 A per contact
- Dual-row vertical through-hole construction for secure board attachment
- Gold-plated copper contacts ensuring reliable conductivity
- Black LCP housing providing thermal stability up to 105°C
Applications
- Industrial power distribution systems
- Telecommunications equipment power interfaces
- Server and storage system power connections
- Automotive electronics power modules
Procurement Notes
Verify the complete part number including the suffix to confirm plating thickness and material specifications. Ensure compatibility with the target PCB footprint and mating connector requirements. Confirm RoHS compliance status if required by project regulations. Check lead times as this component may be subject to special order processing.
Selection Notes
Select this connector when high current capacity and robust mechanical retention are required in a vertical configuration. The 4.2 mm pitch accommodates larger gauge wires compared to standard signal headers. Verify that the operating environment does not exceed the 105°C maximum temperature rating. Ensure the mating connector matches the dual-row, gold-plated interface specifications.
Part Context
This component belongs to the Minitek Pwr 4.2 family, engineered for demanding power delivery scenarios. The series emphasizes high current handling and durability in industrial and telecom environments. The specific model represents a six-position variant within the broader product line, offering a balance between compact size and power capacity.
Replacement Considerations
No direct public substitute part numbers are confirmed for this specific component.
FAQ
Is this connector glow wire compatible?
No, the documentation indicates this specific model is non-glow wire compatible.
What is the contact plating material?
The contacts are made of copper with a gold plating finish.
