Product Detailed Parameters
- Description：CONN HEADER VERT 8POS 4.2MM
- Series：Minitek® Pwr 4.2 High Current
- Mfr：Amphenol ICC (FCI)
- Package：Tray
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.165" (4.20mm)
- Number of Positions：8
- Number of Rows：2
- Row Spacing - Mating：0.165" (4.20mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：0.138" (3.50mm)
- Overall Contact Length：-
- Insulation Height：0.504" (12.80mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Polyamide (PA66), Nylon 6/6
- Features：-
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：Varies by Wire Gauge
- Voltage Rating：600VAC/DC
Download product information
Overview
The Amphenol ICC (FCI) part number 10131319-0812100LF is a Minitek Power4.2 series power-to-board connector header. It features an 8-position configuration with a 4.2 mm pitch and dual-row arrangement. The component utilizes tin-plated copper contacts and operates within a temperature range of -40°C to +105°C. Designed for vertical surface-mount installation, it supports a current rating of 12.5 A per contact. The housing is natural-colored thermoplastic with an insulation resistance of 1 GOhm.
Feature Summary
- Vertical surface-mount header design for direct board integration
- Dual-row configuration providing high-density power distribution
- Robust tin-plated copper contact system ensuring reliable conductivity
Applications
- Server and storage equipment power distribution
- Data communication infrastructure hardware
- Industrial instrumentation power interfaces
Procurement Notes
Verify the specific ordering suffix against manufacturer documentation to confirm plating type and packaging format. Confirm lead times as this item may be subject to special order requirements. Ensure compatibility with mating receptacles from the same Minitek Power4.2 family before finalizing procurement specifications.
Selection Notes
Select this component when a vertical, dual-row power interface with a 4.2 mm pitch is required. Ensure the application environment stays within the specified -40°C to +105°C operating range. Verify that the PCB layout accommodates the specific footprint dimensions and that the 12.5 A current rating meets the circuit load requirements.
Part Context
This connector belongs to the Minitek Power4.2 family, designed for high-current applications in datacom and industrial sectors. The series offers various pin counts and termination options, providing standardized solutions for power delivery in compact electronic assemblies manufactured by Amphenol ICC.
Replacement Considerations
Compatible substitutes include other 8-position, 4.2 mm pitch vertical headers from the Minitek Power4.2 line. Cross-reference mating receptacle part numbers to ensure mechanical and electrical compatibility.
