Product Detailed Parameters
- Description：CONN HEADER VERT
- Series：Minitek® Pwr 4.2 High Current
- Mfr：Amphenol ICC (FCI)
- Package：Tray
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.165" (4.20mm)
- Number of Positions：10
- Number of Rows：2
- Row Spacing - Mating：0.165" (4.20mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：0.138" (3.50mm)
- Overall Contact Length：-
- Insulation Height：0.504" (12.80mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Liquid Crystal Polymer (LCP)
- Features：-
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：Varies by Wire Gauge
- Voltage Rating：600VAC/DC
Download product information
Overview
The Amphenol ICC (FCI) part number 10131319-1012200LF is a vertical power connector header belonging to the Minitek Power 4.2 series. It features a 10-position configuration with a 4.2 mm pitch and two rows of contacts. The connector utilizes tin-plated copper terminals and is designed for surface-mount installation on printed circuit boards. This component supports a current rating of 12.5 A per contact and operates within a temperature range of -40°C to +105°C. The housing is constructed from natural-colored insulating material, ensuring reliable electrical performance in power distribution applications.
Feature Summary
- Vertical through-hole or surface-mount header design for board-to-board power connections
- High current capacity rated at 12.5 A per position for efficient power delivery
- Dual-row configuration providing compact layout optimization for high-density circuits
Applications
- Server and storage system power distribution modules
- Telecommunications equipment internal power routing
- Industrial control board power interface connections
Procurement Notes
Verify the specific suffix requirements against the manufacturer's latest documentation before ordering. Confirm that the tin plating specification aligns with your assembly process constraints. Ensure compatibility with existing PCB footprint designs regarding row spacing and mounting hole dimensions. Check for any recent product change notices affecting lead times or material composition updates.
Selection Notes
Select this component when a robust 4.2 mm pitch power solution is required for vertical mounting configurations. Consider the 12.5 A current rating suitability for your specific load requirements. Evaluate the operating temperature range limits against your environmental conditions. Compare physical dimensions against available board space to ensure proper fitment within the enclosure constraints.
Part Context
This connector belongs to the Minitek Power 4.2 family, which provides standardized solutions for high-current applications. The series offers various pin counts and mounting options to support diverse power distribution needs across different electronic systems. Amphenol ICC manufactures these components to meet rigorous reliability standards for industrial and commercial use cases.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify cross-compatibility carefully if considering alternative suppliers due to potential differences in mechanical tolerances and plating specifications.
