10131319-16111G0LF

Overview

The Amphenol ICC (FCI) part number 10131319-16111G0LF is a Minitek Pwr 4.2 High Current Header connector designed for power-dense applications. It features a 16-position, single-row configuration with a 4.2 mm pitch. The component utilizes through-hole mounting and offers a vertical orientation. Contact plating is gold, ensuring reliable conductivity. The housing is black, constructed from high-performance thermoplastic suitable for industrial environments.

Feature Summary

• High current capacity up to 13.5A per contact
• Gold-plated contacts for enhanced reliability
• Vertical through-hole mounting style

Applications

• Power distribution systems
• Industrial equipment
• Server infrastructure

Procurement Notes

Verify the specific suffix 'G0LF' against official Amphenol documentation to confirm RoHS compliance and lead-free status. Ensure the ordering code matches the exact pin count and plating thickness required by your design specifications before finalizing procurement.

Selection Notes

Select this header when a 16-position vertical connection is needed. The 4.2mm pitch supports higher current loads compared to standard signal headers. Confirm that the PCB footprint aligns with the Minitek Pwr 4.2 mechanical dimensions for proper assembly.

Part Context

This component belongs to the Minitek Pwr 4.2 series, engineered for high-current power-to-board connections. It serves as a robust interface between power sources and circuit boards in demanding electronic systems requiring stable electrical performance.

Replacement Considerations

Direct substitutes within the same series include 10131319-08421G0LF (8 positions) or 10131319-24122GRLF (24 positions). Verify mechanical compatibility and electrical ratings before cross-referencing with other manufacturers.
