10131319-1841100LF

Overview

The Amphenol ICC (FCI) part number 10131319-1841100LF is a Minitek Pwr 4.2 Higher Current Connector (HCC) header designed for power-dense applications. It features a 6-position, 2-row configuration with a 4.2mm pitch. The connector supports a current rating of up to 13.5A per contact and operates within a temperature range of -40°C to +105°C. Contact materials consist of copper alloy with gold plating on the mating surface (30.0µin thickness) and tin plating on the post. The housing is made of polyamide (PA66/Nylon 6/6), and it utilizes vertical through-hole termination.

Feature Summary

• Designed for high-current power delivery in dense electronic assemblies
• Utilizes gold-plated contacts for reliable signal integrity and corrosion resistance
• Constructed with thermally stable polyamide insulation material

Applications

• Power distribution modules
• Industrial instrumentation systems
• Data communication equipment power interfaces

Procurement Notes

Verify component authenticity through authorized Amphenol channels due to potential counterfeit risks. Confirm RoHS compliance status as indicated by the LF suffix against specific project requirements. Validate pin count and orientation specifications against PCB layout designs prior to ordering. Ensure storage conditions maintain moisture sensitivity level integrity before reflow soldering processes.

Selection Notes

Select this component when high current capacity per contact is required alongside standard board-to-board connectivity. The 4.2mm pitch allows for robust power traces while maintaining compact form factors. Consider the vertical mounting style for space-constrained enclosures requiring direct board insertion. Evaluate thermal management needs given the 105°C maximum operating temperature limit.

Part Context

This connector belongs to the Minitek Pwr 4.2 series, engineered specifically for higher current applications compared to standard signal connectors. The HCC designation highlights its capability to handle significant electrical loads without excessive heating. As part of Amphenol's portfolio, it integrates with broader interconnect ecosystems for server and industrial infrastructure.

Replacement Considerations

No public confirmed substitute part numbers are available in official documentation. Direct replacement requires matching pitch, current rating, and mechanical dimensions. Consult Amphenol engineering for cross-reference validation if original stock is unavailable.
