10131319-204110PLF

Overview

The Amphenol ICC (FCI) part number 10131319-204110PLF is a Minitek Power4.2HCC double-row vertical header designed for power-to-the-board applications. It features 20 positions with a 4.2 mm pitch and supports a current rating of 12.5 A. The connector utilizes copper contacts plated with 30 microinches of gold, housed in a natural-colored shell. Operating within a temperature range of -40°C to +105°C, it offers an insulation resistance of 1 GOhms.

Feature Summary

• Designed for high-current density power distribution using the Minitek Power4.2HCC series architecture.
• Provides reliable electrical connections through gold-plated copper contacts ensuring low contact resistance.
• Supports vertical surface mounting via through-hole solder termination for secure board attachment.

Applications

• Power-dense electronic systems requiring robust power delivery
• Industrial equipment power distribution boards
• Telecommunications infrastructure power modules

Procurement Notes

Verify the specific ordering suffix PLF against official manufacturer documentation to confirm plating thickness and material specifications. Ensure compatibility with mating receptacles regarding current ratings and thermal limits. Cross-reference the component datasheet for precise mechanical dimensions and soldering profile requirements before integration into production designs.

Selection Notes

Select this component when designing systems that require high current capacity per contact within a compact form factor. The 4.2 mm pitch allows for substantial conductor spacing, reducing arcing risks. Verify that the operating environment remains within the specified temperature range and that the vertical orientation aligns with the system's mechanical constraints.

Part Context

This connector belongs to the Minitek Pwr 4.2 series, engineered for applications demanding higher current handling than standard signal connectors. The HCC designation indicates optimized contact geometry for improved thermal performance. As part of the Amphenol FCI portfolio, it integrates established reliability standards for industrial and commercial electronic interconnect solutions.

Replacement Considerations

Direct substitutes must match the 20-position count, 4.2 mm pitch, and double-row vertical configuration. Verify identical current ratings and contact plating specifications to maintain electrical continuity. Consult official cross-reference lists for equivalent components from the same manufacturer family.
