10131319-20411GPLF

Overview

The Amphenol ICC (FCI) 10131319-20411GPLF is a Minitek Power 4.2HCC double row vertical header designed for power-to-board applications. It features a 4.2 mm pitch and contains 2 positions with copper contacts plated with 30 microns of gold. The connector supports a current rating of 12.5 A and operates within a temperature range of -40°C to +105°C. It has an insulation resistance of 1 GOhms, a natural colored housing, and utilizes a vertical mounting angle.

Feature Summary

• High-density pin-and-socket cable-to-board system optimized for compact, power-dense applications
• Double row vertical header configuration providing robust power distribution
• Gold-plated contacts ensure reliable conductivity and corrosion resistance

Applications

• Compact electronic systems requiring high power density
• Power distribution in board-level interconnects
• Industrial equipment with space-constrained power requirements

Procurement Notes

Verify the specific ordering suffix against official Amphenol FCI documentation to confirm contact plating thickness and housing material specifications. Ensure compatibility with mating socket components regarding pitch and row configuration. Request manufacturer datasheets to validate thermal performance limits and current derating curves for your specific operating environment before finalizing procurement.

Selection Notes

Select this component when a 4.2 mm pitch vertical header is required for power delivery. Confirm that the 12.5 A current rating meets circuit demands. Verify that the double-row format aligns with PCB layout constraints. Check that the 30-micron gold plating satisfies environmental durability requirements compared to tin alternatives.

Part Context

This part belongs to the MinitekPwr 4.2 series, a family of connectors engineered for flexible power management solutions. The series supports various configurations including cable-to-board and board-to-board interconnects. Amphenol FCI designs these connectors to address the growing demand for efficient power handling in dense electronic architectures.

Replacement Considerations

Consult official substitution guides for compatible headers within the Minitek Power 4.2 series. Verify mechanical dimensions and electrical ratings match exactly. No direct substitute part numbers are confirmed in public data.
