10131319-2212100LF

Description：CONN HEADER VERT 22POS 4.2MM
Series：Minitek® Pwr 4.2 High Current
Mfr：Amphenol ICC (FCI)
Package：Tray

SKU:cb768e2abeb1 Category: Headers, Male Pins Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HEADER VERT 22POS 4.2MM
Series：Minitek® Pwr 4.2 High Current
Mfr：Amphenol ICC (FCI)
Package：Tray
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.165" (4.20mm)
Number of Positions：22
Number of Rows：2
Row Spacing - Mating：0.165" (4.20mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Locking Ramp
Contact Length - Mating：-
Contact Length - Post：0.138" (3.50mm)
Overall Contact Length：-
Insulation Height：0.504" (12.80mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：Flash
Contact Finish - Post：-
Contact Material：Copper Alloy
Insulation Material：Polyamide (PA66), Nylon 6/6
Features：-
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：Varies by Wire Gauge
Voltage Rating：600VAC/DC

Download product information

10131319-2212100LF

Overview

The Amphenol ICC (FCI) part number 10131319-2212100LF is a vertical through-hole header belonging to the Minitek Power4.2 series. It features 22 positions with a 4.2 mm pitch and utilizes gold flash contact plating. Designed for power-to-board applications, this connector supports high current ratings of 12.5 A per contact. The housing is natural-colored, and the component is supplied in reel packaging suitable for automated surface mounting processes.

Feature Summary

Vertical through-hole design for direct board integration
High current capacity rated at 12.5 A per contact
Gold flash contact plating for reliable conductivity
Minitek Power4.2 series construction for robust power distribution

Applications

Power distribution in server infrastructure
Data communication equipment power interfaces
Industrial instrumentation power connections

Procurement Notes

Verify the specific ordering suffix against the manufacturer's latest datasheet to ensure correct pin count and plating specifications. Confirm RoHS compliance status as indicated by the LF suffix. Check for obsolescence notices or lifecycle changes directly from Amphenol ICC before finalizing procurement plans.

Selection Notes

Select this component when a vertical orientation and 4.2 mm spacing are required for power delivery. Ensure the application environment stays within the specified temperature range. Verify that the 12.5 A current rating meets the circuit requirements without exceeding thermal limits.

Part Context

This connector is part of the Minitek Power4.2 family, engineered for dense power distribution in compact electronic assemblies. The series is widely used in datacom and industrial sectors where reliable high-current connections are essential. Amphenol ICC provides these solutions for robust system interconnectivity.
