10131319-22411GPLF

Overview

The Amphenol ICC (FCI) part number 10131319-22411GPLF is a Minitek Pwr 4.2 Higher Current Connectors (HCC) header designed for power-dense applications. It features a 2-position configuration with a 4.2 mm pitch and supports a current rating of 12.5 A per contact. The connector utilizes copper contacts with 30-microinch gold plating and operates within a temperature range of -40°C to +105°C. Constructed with natural-colored insulation rated UL94 V-0, it offers an insulation resistance of 1 GOhm. This vertical, through-hole component is engineered for reliable electrical connections in demanding environments.

Feature Summary

• Designed for high-current power delivery in compact, power-dense electronic systems
• Utilizes durable copper contacts with gold plating for stable signal integrity
• Features robust natural-colored insulation ensuring compliance with safety standards

Applications

• Server and storage equipment power distribution
• Communication device internal power interfaces
• Industrial control system board-to-board connections

Procurement Notes

Verify the specific ordering suffix and manufacturer documentation to confirm exact pin count and current ratings before integration. Contact the manufacturer or authorized distributors directly for availability and lead time information, as standard stock levels may vary. Ensure that the selected component matches the required mechanical and electrical specifications for your specific application design.

Selection Notes

Select this component when a 4.2 mm pitch power connector with a 12.5 A rating is required. Consider the vertical mounting style and through-hole termination method for PCB integration. Evaluate the operating temperature range and flammability rating against environmental conditions. Confirm compatibility with mating receptacles within the Minitek Pwr 4.2 series for proper assembly.

Part Context

This component belongs to the Minitek Pwr 4.2 series by Amphenol FCI, a line specialized for higher current applications. The series provides solutions for power-dense environments found in servers, storage, and communication infrastructure. Amphenol acquired FCI to expand its portfolio of reliable interconnect solutions, focusing on signal integrity and power management for commercial electronics.

Replacement Considerations

Consult official substitution guides from Amphenol ICC (FCI) for verified alternative part numbers. Ensure any replacement maintains identical pitch, current rating, and mechanical dimensions. Cross-reference datasheets to verify compatibility with existing PCB layouts and mating connectors.
