Product Detailed Parameters
- Description：CONN PWR4.2 HCC RA
- Series：Minitek® Pwr 4.2 High Current
- Mfr：Amphenol ICC (FCI)
- Package：Tray
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.165" (4.20mm)
- Number of Positions：3
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：0.138" (3.50mm)
- Overall Contact Length：-
- Insulation Height：-
- Contact Shape：Square
- Contact Finish - Mating：Tin
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：Tin
- Contact Material：Copper Alloy
- Insulation Material：Liquid Crystal Polymer (LCP)
- Features：Board Lock
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：-
- Voltage Rating：600V
Download product information
Overview
The Amphenol ICC (FCI) part number 10137784-03124LF is a power connector belonging to the Minitek Pwr 4.2 series. It is designed as a header with male pins, featuring a right-angle orientation for surface mount installation. The connector provides three positions with a pitch of 4.2 mm. It utilizes gold-plated contacts and is rated for a current of 12.5 A per contact. The unit operates within a temperature range of -40°C to +105°C and meets UL94 V-0 flammability standards for its insulating material.
Feature Summary
- Right-angle surface mount design facilitates compact board layout integration.
- Gold-plated contacts ensure reliable electrical performance and corrosion resistance.
- High current rating supports demanding power distribution requirements.
Applications
- Power distribution in server infrastructure
- Storage device internal connections
- Communication equipment power interfaces
Procurement Notes
Verify component authenticity through authorized channels. Confirm RoHS compliance status and lead times directly with suppliers. Check for obsolescence notices or product change notifications prior to procurement. Ensure storage conditions align with moisture sensitivity levels specified in official documentation.
Selection Notes
Select this component for applications requiring high-current power delivery in space-constrained environments. The right-angle form factor aids in managing board height profiles. Verify that the 4.2 mm pitch matches the target PCB footprint and mating connector specifications.
Part Context
This connector is part of the Minitek Pwr 4.2 family, engineered for robust power-to-board connections. The series is widely utilized in data center and enterprise hardware where reliability under thermal stress is critical. It complements other components in the FCI ecosystem for complete system interconnect solutions.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Consult manufacturer engineering resources for potential cross-references if this specific variant is unavailable.
