Product Detailed Parameters
- Description：CONN PWR4.2 HCC VT
- Series：Minitek® Pwr 4.2 High Current
- Mfr：Amphenol ICC (FCI)
- Package：Tray
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.165" (4.20mm)
- Number of Positions：4
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder Cup
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：0.138" (3.50mm)
- Overall Contact Length：-
- Insulation Height：0.504" (12.80mm)
- Contact Shape：Rectangular
- Contact Finish - Mating：Tin
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Liquid Crystal Polymer (LCP)
- Features：Board Lock
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：-
- Voltage Rating：600V
Download product information
Overview
The Amphenol ICC (FCI) part number 10137785-041241LF is a Minitek Pwr 4.2 series header connector designed for power-to-board applications. It features a 4-position configuration with a 4.2mm pitch and operates within a temperature range of -40°C to +105°C. The component utilizes tin-plated copper alloy contacts housed in black liquid crystal polymer (LCP). Rated for 600V AC, it supports a current capacity of 12.5A per contact. This right-angle, single-row through-hole header employs a vertical termination style.
Feature Summary
- Vertical termination design for through-hole mounting
- High voltage rating suitable for power distribution
- Robust LCP insulation material for thermal stability
Applications
- Power distribution systems
- Server and storage equipment
- Communication devices
Procurement Notes
Verify the specific suffix against official documentation to confirm plating and orientation details. Ensure compatibility with mating receptacles regarding pitch and row configuration. Confirm that the through-hole vertical termination aligns with the target PCB layout requirements before finalizing procurement.
Selection Notes
Select this component when a high-current, right-angle power connection is required between a cable or harness and a printed circuit board. The 4.2mm pitch accommodates heavier gauge wires compared to signal connectors. Verify that the 12.5A rating meets the specific circuit load requirements and that the operating temperature range covers the environmental conditions.
Part Context
This connector belongs to the Minitek Pwr 4.2 family, engineered for robust power delivery in dense electronic assemblies. The series is widely utilized in infrastructure and industrial sectors where reliable electrical connections under demanding thermal and mechanical stress are critical for system longevity.
Replacement Considerations
Consult official substitution lists for compatible alternatives. Cross-reference pin counts, pitch dimensions, and termination styles to ensure functional equivalence without modifying the host board design.
