Product Detailed Parameters
- Description：CONN HEADER SMD R/A 4POS 3MM
- Series：Minitek® Pwr 3.0
- Mfr：Amphenol ICC (FCI)
- Package：Tape & Reel (TR),Cut Tape (CT)
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.118" (3.00mm)
- Number of Positions：4
- Number of Rows：2
- Row Spacing - Mating：0.118" (3.00mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Surface Mount, Right Angle
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.290" (7.37mm)
- Contact Shape：Square
- Contact Finish - Mating：Tin
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Liquid Crystal Polymer (LCP), Halogen Free
- Features：Solder Retention
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：Varies by Wire Gauge
- Voltage Rating：600VAC/DC
Download product information
Overview
The Amphenol ICC (FCI) part number 10137924-0411LF is a Minitek Power 3.0 series rectangular power connector header. It features a surface mount right-angle termination with four positions and a 3.00 mm pitch. The contacts are male pins made of copper alloy with tin plating, housed in black liquid crystal polymer insulation. Rated for 600V and operating within -40°C to +105°C, it utilizes a locking pin rail system.
Feature Summary
- Right-angle surface mount design for compact board integration
- Locking pin rail mechanism ensures secure mating stability
- Halogen-free liquid crystal polymer insulation for reliability
Applications
- Power distribution on printed circuit boards
- Industrial equipment internal power connections
- Commercial electronic device power interfaces
Procurement Notes
Verify the specific ordering suffix against official manufacturer documentation to confirm contact plating and packaging details. Ensure compatibility with mating receptacles regarding pitch and locking mechanisms. Confirm that the surface mount footprint matches the target PCB layout requirements before finalizing procurement orders.
Selection Notes
Select this component when a low-profile, right-angle power header is required for surface mounting. The 3.00 mm pitch accommodates higher current applications compared to signal connectors. Verify that the tin-plated contacts meet the environmental and conductivity requirements of the specific application environment.
Part Context
This connector belongs to the Minitek Power 3.0 family, designed for robust power transmission in space-constrained environments. The series offers various position counts and termination styles to support diverse board-to-board and cable-to-board power interconnection needs across industrial and commercial sectors.
Replacement Considerations
Direct substitutes must match the 3.00 mm pitch, 4-position count, right-angle SMT form factor, and male pin configuration. Verify identical housing material properties and locking mechanism types to ensure mechanical interchangeability without redesigning the PCB or mating hardware.
