10137924-2412LF

$1.56

Description：CONN PWR3.0 R/A SMT
Series：Minitek® Pwr 3.0
Mfr：Amphenol ICC (FCI)
Package：Tray

SKU:60d6bbb16f7b Category: Headers, Male Pins Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN PWR3.0 R/A SMT
Series：Minitek® Pwr 3.0
Mfr：Amphenol ICC (FCI)
Package：Tray
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.118" (3.00mm)
Number of Positions：24
Number of Rows：2
Row Spacing - Mating：0.118" (3.00mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Fastening Type：Locking Ramp
Contact Length - Mating：-
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.290" (7.37mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：-
Contact Finish - Post：-
Contact Material：Copper Alloy
Insulation Material：Liquid Crystal Polymer (LCP), Halogen Free
Features：Solder Retention
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：Varies by Wire Gauge
Voltage Rating：600VAC/DC

Download product information

10137924-2412LF

Overview

The Amphenol ICC (FCI) part number 10137924-2412LF is a Minitek Pwr 3.0 series power-to-board header connector designed for surface mount technology. It features a right-angle configuration with 24 positions arranged in two rows and a 3.00 mm pitch. The contacts are gold-plated copper alloy pins rated for up to 8.5 A per contact and 600 VAC. Constructed with liquid crystal polymer insulation, it operates within a temperature range of -40°C to +105°C and meets UL94 V-0 flammability standards.

Feature Summary

High current capacity suitable for power distribution applications
Right-angle surface mount design for compact board integration
Gold-plated contacts ensure reliable signal and power transmission

Applications

Server and storage system power distribution
Communication equipment internal power connections
Industrial control board power interfaces

Procurement Notes

Verify the specific suffix against official manufacturer documentation to confirm pin count, plating thickness, and packaging type. Ensure compatibility with mating receptacles and PCB footprint requirements before procurement. Confirm RoHS compliance status through current datasheets.

Selection Notes

Select this component when high-current power delivery is required in a space-constrained environment. The right-angle SMT form factor aids in dense board layouts. Verify thermal management needs as high current ratings may require adequate copper area on the PCB.

Part Context

This connector belongs to the Minitek Pwr 3.0 family from Amphenol ICC (FCI), formerly FCI. The series specializes in robust power interconnects for demanding environments. It complements other Minitek variants by offering higher current handling capabilities compared to standard signal connectors.
