10137926-2412LF

Overview

The Amphenol ICC (FCI) part number 10137926-2412LF is a Minitek Power 3.0 series power header connector designed for surface mount technology applications. This component features a dual-row configuration with 24 positions, providing a robust connection interface for high-current power distribution on printed circuit boards. The connector utilizes a 3.00 mm (0.118 inch) mating pitch and a 3.00 mm row spacing to accommodate substantial wire gauges. Constructed with copper alloy contacts finished with tin plating, it ensures reliable conductivity and corrosion resistance. The housing is made from black liquid crystal polymer (LCP), offering excellent thermal stability and flame retardancy rated at UL94 V-0. Designed for board-to-cable or board-to-wire connections, this right-angle header supports a maximum operating temperature range of -40°C to +105°C. It is rated for 600V and carries an 8.5A current rating per contact, making it suitable for demanding industrial and commercial power supply environments.

Feature Summary

• Dual-row surface mount design with 24 positions for high-density power routing
• Tin-plated copper alloy contacts ensure stable electrical performance
• UL94 V-0 rated LCP insulation provides thermal and fire safety
• Right-angle orientation facilitates compact PCB layout integration

Applications

• Industrial control system power distribution modules
• Commercial server and storage equipment power supplies
• Telecommunications infrastructure power interfaces
• Automotive electronics power connection systems

Procurement Notes

Verify the specific ordering suffix to confirm contact plating and packaging details. Ensure compatibility with mating cable assemblies regarding wire gauge and termination style. Confirm that the surface mount footprint matches the target PCB design guidelines. Check for RoHS compliance status if required by project specifications. Validate the current rating against the actual load requirements of the application.

Selection Notes

Select this connector when a high-current, dual-row surface mount solution is required. The 3.00mm pitch allows for larger conductors compared to standard signal headers. Consider the right-angle form factor for space-constrained vertical mounting scenarios. Evaluate the tin plating option against environmental conditions where gold might be preferred for long-term reliability in corrosive atmospheres.

Part Context

This component belongs to the Minitek Power 3.0 family, which focuses on efficient power delivery through compact connectors. The series is characterized by its ability to handle significant currents while maintaining a small footprint. It complements other products in the Amphenol ICC portfolio designed for modern electronic manufacturing needs.

Replacement Considerations

Direct substitutes within the same series include 10137926-0412LF and 10137926-0242LF, though these differ in position count and pin configuration. Verify mechanical dimensions and electrical ratings before cross-referencing with alternative manufacturers' offerings.
