10138654-G04-02LF

Overview

The Amphenol ICC (FCI) 10138654-G04-02LF is a Minitek series header connector designed for surface mount applications. It features a dual-row configuration with 4 positions and a 2.00mm pitch. The contacts are gold-plated copper alloy, ensuring reliable conductivity. The housing is constructed from thermoplastic material rated UL94 V-0. This component supports pin-in-paste processes and operates within a temperature range of -55°C to 125°C.

Feature Summary

• Gold-plated contacts enhance conductivity and durability
• Thermoplastic insulation provides structural integrity
• Supports pin-in-paste manufacturing processes

Applications

• Communication equipment interconnects
• Data processing system connections
• Industrial control module interfaces

Procurement Notes

Verify the specific ordering suffix to confirm contact finish and insulation material properties. Ensure the selected variant matches the required surface mount orientation and pitch specifications for the target PCB layout. Confirm RoHS compliance status through official manufacturer documentation prior to final procurement decisions.

Selection Notes

Select this component when a low-profile, dual-row surface mount header is required for high-density board-to-board or board-to-wire connections. Consider the 2.00mm pitch and gold contact finish for applications demanding robust signal integrity and corrosion resistance in industrial environments.

Part Context

This part belongs to the Amphenol ICC Minitek series, which specializes in compact, high-reliability interconnect solutions. The series is engineered for modern electronics requiring space-efficient mounting options while maintaining electrical performance standards across various operating conditions.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
