Product Detailed Parameters
- Description：CONN PWR3.0 BMI
- Series：Minitek® Pwr 3.0
- Mfr：Amphenol ICC (FCI)
- Package：Tray
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.118" (3.00mm)
- Number of Positions：16
- Number of Rows：2
- Row Spacing - Mating：0.118" (3.00mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Kinked Pin, Solder
- Fastening Type：-
- Contact Length - Mating：-
- Contact Length - Post：0.130" (3.30mm)
- Overall Contact Length：-
- Insulation Height：0.457" (11.60mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：30.0µin (0.76µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Liquid Crystal Polymer (LCP)
- Features：Board Guide, Glow Wire Compliant
- Operating Temperature：-40°C ~ 150°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：Varies by Wire Gauge
- Voltage Rating：600V
Download product information
Overview
The Amphenol ICC (FCI) 10138980-1641LF is a rectangular connector component belonging to the Verio™ series. It is designed as a header with right-angle through-hole termination for board-to-cable or wire applications. The connector features a total of 16 positions, configured with 12 signal contacts and 2 dedicated power contacts. The housing utilizes a shielded design with four walls to provide electromagnetic interference protection. Contact surfaces are gold-plated for the mating interface, while pins are tin-plated. The unit operates within a temperature range of -55°C to 85°C and meets UL94 V-0 flammability standards.
Feature Summary
- Shielded header design with four-wall construction for enhanced EMI protection
- Mixed contact configuration supporting both signal and power transmission requirements
- Right-angle through-hole mounting style optimized for space-constrained PCB layouts
Applications
- Industrial control systems requiring robust signal integrity
- Data communication equipment utilizing board-to-wire interconnections
- Automotive electronics assemblies needing shielded connectivity solutions
Procurement Notes
Verify the specific pin count and shielding configuration against the official datasheet before integration. Confirm that the right-angle orientation matches the mechanical constraints of the target printed circuit board assembly. Ensure compatibility with mating cable harnesses regarding contact spacing and insulation thickness.
Selection Notes
Select this component when a shielded, right-angle header is required for mixed signal and power applications. The Verio™ series offers reliable performance in environments demanding high durability. Consider the through-hole termination method for secure mechanical fixation during vibration-prone operations.
Part Context
This part belongs to the Amphenol ICC (FCI) Verio™ family, which specializes in versatile interconnect solutions. The series provides various configurations for board-to-board and board-to-wire connections. Components in this line are engineered for high reliability across diverse industrial and commercial sectors.
Replacement Considerations
Consult official substitution guides for equivalent shielded headers from the same manufacturer. Verify mechanical dimensions and electrical ratings match exactly before replacing.
