10151422-0212110LF

Description：R/A SMT PCIE GEN4
Series：-
Mfr：Amphenol ICC (FCI)
Package：Bulk

SKU:4c8c16f41379 Category: Edgeboard Connectors Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

10151422-0212110LF is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists Amphenol ICC (FCI). Its product description is R/A SMT PCIE GEN4. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 10151422-0212110LF

Description：R/A SMT PCIE GEN4
Series：-
Mfr：Amphenol ICC (FCI)
Package：Bulk
Card Type：PCI Express™
Gender：Female
Number of Positions/Bay/Row：49
Number of Positions：98
Card Thickness：0.063" (1.60mm)
Number of Rows：2
Pitch：0.039" (1.00mm)
Read Out：Dual
Features：Board Guide
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：30.0µin (0.76µm)
Contact Type：-
Color：Black
Flange Feature：-
Operating Temperature：-

Edgeboard Connectors datasheet and documents for 10151422-0212110LF

10151422-0212110LF

Edgeboard Connectors Overview

The Amphenol ICC (FCI) 10151422-0212110LF is a PCI Express card edge connector designed for surface mount installation. It features 98 positions with a 1mm pitch and utilizes a right-angle configuration to facilitate compact board layouts. The component is engineered to support high-speed data transmission, aligning with the requirements of next-generation data and communication applications.

Edgeboard Connectors Feature Summary

Supports high-speed signal integrity for advanced data and communication protocols
Right-angle design enables efficient vertical space utilization on printed circuit boards
Surface mount termination ensures secure attachment during automated assembly processes

Edgeboard Connectors Applications

Next-generation data processing systems
High-speed communication infrastructure equipment
PCI Express compliant expansion cards

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to ensure correct pin configuration and termination style. Confirm that the surface mount footprint matches the target PCB design. Check for RoHS compliance status and moisture sensitivity levels prior to procurement to ensure storage and handling requirements are met.

Edgeboard Connectors Selection Notes

Select this component when a right-angle, surface-mount interface is required for PCI Express applications. The 1mm pitch allows for dense I/O arrangements in constrained spaces. Ensure the receiving board supports the necessary solder paste volume and reflow profile for reliable joint formation.

Edgeboard Connectors Part Context

This part belongs to the PCI Express / PCI connector category from Amphenol FCI. It is designed to provide robust interconnect solutions for modern computing architectures. The product line focuses on delivering reliable performance for demanding digital environments requiring high bandwidth capabilities.
