Overview

The SICK DKS40-A5J02048 is an industrial incremental encoder designed for precise rotational position and speed measurement. It utilizes a contactless reading method to ensure durability and reliability in demanding environments. The device features a robust housing with an external diameter of 40 mm and an overall length of 150 mm. It provides a resolution of 2048 pulses per revolution, suitable for high-precision automation tasks. The unit operates on a supply voltage range of 10 to 30 V DC and delivers push-pull output signals for compatibility with standard PLC inputs.

Feature Summary

• Contactless sensing technology eliminates mechanical wear for extended service life
• Robust aluminum housing design ensures resistance to vibration and shock
• High-resolution pulse output supports accurate closed-loop control applications

Applications

• Rotary axis positioning in automated machinery
• Speed monitoring in conveyor systems
• Position feedback in packaging equipment

Procurement Notes

Verify the specific part number against official SICK documentation to confirm electrical characteristics and pinout configurations. Ensure the selected variant matches the required mounting dimensions and shaft type for your application. Cross-reference the manufacturer's datasheet for environmental ratings and signal compatibility before procurement.

Selection Notes

Select this model based on the requirement for a 40 mm frame size encoder with a 2048 ppr resolution. Confirm that the push-pull output interface aligns with your controller's input specifications. Evaluate the operating temperature range and protection class requirements against the installation environment conditions.

Part Context

This component belongs to the DKS40 series of incremental encoders from SICK. The series is characterized by its compact design and versatile mounting options. Other variants in the family offer different resolutions and output types, but this specific model is defined by its 2048 pulse count and contactless read head technology.

Replacement Considerations

Direct replacements must match the 40 mm diameter, 150 mm length, and 2048 ppr resolution. Verify shaft coupling compatibility and electrical interface alignment. Consult SICK's replacement guide for updated models or cross-references within the DKS40 lineup.
