1048476

Overview

The SICK part number 1048476 corresponds to the M20S-081A2A122 safety light curtain. This device features eight light beams with a resolution of 16 mm and a vertical scanning range of 25 mm. It is designed for protective operation with beam coding and includes External Device Monitoring (EDM) capabilities. The unit utilizes an M12, 8-pin male connector for interface connectivity. These specifications define the physical and electrical parameters for this specific variant within the M2000 Standard series.

Feature Summary

• Provides protective operation functionality with integrated beam coding technology
• Includes External Device Monitoring (EDM) for enhanced system safety verification
• Features a compact design suitable for mobile applications and worldwide use

Applications

• Protective monitoring in industrial automation environments
• Safety guarding for machinery requiring high-resolution detection
• Applications necessitating external device monitoring integration

Procurement Notes

Verify that the required configuration matches the M20S-081A2A122 variant specifically. Confirm compatibility with the intended safety controller regarding EDM requirements and M12 connector interfaces. Ensure environmental conditions align with the device specifications. Cross-reference the ordering number 1048476 with official SICK documentation to validate the exact feature set before procurement.

Selection Notes

Select this model when eight-beam resolution with 16 mm spacing is required for protective zones. Choose this variant if External Device Monitoring is a mandatory safety function for the application. Consider the M12 connector type for wiring compatibility. Evaluate the 25 mm scanning range against the specific safety distance requirements of the machine guard setup.

Part Context

This component belongs to the SICK M2000 Standard series of safety light curtains. The series is characterized by robust construction and versatile configuration options. Part 1048476 represents a specific configuration within this family, distinguished by its beam count, resolution, and connector type compared to other variants like the M20E series or different beam configurations.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
