1053194

Overview

The SICK part number 1053194 corresponds to the RFU610-10605, a short-range UHF RFID read/write device with an integrated antenna. It operates in the 860 MHz to 960 MHz frequency band with carrier frequencies of 920.625 MHz and 924.375 MHz. The unit delivers an output power of 25 mW (ERP, 14 dBm) and supports EPCglobal UHF Class 1 Generation 2, ISO/IEC 18000-6 C, and RAIN modulation standards. Connectivity is provided via PoE. The integrated antenna features an aperture angle of 110°, a typical axial ratio of 3 dB, and a front-to-back ratio exceeding 5 dB. Reading range is up to 0.5 meters depending on transponder and ambient conditions.

Feature Summary

• Integrated antenna design for compact installation
• Compliance with EPCglobal UHF Class 1 Gen 2 and ISO/IEC 18000-6 C standards
• PoE connectivity for simplified power and data transmission
• Configurable transmitting power

Applications

• Automated identification over small object distances
• Conveyor technology applications
• Component assembly tracking
• Shipment end product identification

Procurement Notes

Verify that the required regional frequency band matches the specific application environment, as the device supports distinct carrier frequencies for different markets. Confirm that the PoE infrastructure is compatible with the device's power requirements. Ensure the mounting kit, part number 2105772, is included or ordered separately if not bundled. Check for any specific software licensing needs for SOPAS ET configuration tools.

Selection Notes

Select this model for scenarios requiring precise, restricted read ranges rather than long-distance bulk reading. The integrated antenna simplifies mechanical integration compared to external antenna setups. Consider the IP rating and environmental resilience if deployed in harsh industrial settings. Evaluate whether the short-range capability aligns with the specific throughput and identification accuracy requirements of the conveyor system.

Part Context

This component belongs to the SICK RFU61x family of UHF RFID readers designed for machine vision and identification tasks. The RFU61x series focuses on short-range applications, providing high process stability through optimally aligned antenna characteristics. It serves as a foundation for IIoT applications where transparency in production and logistics processes is critical, bridging component assembly to final shipment.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
