1054311107

Headers, Male Pins Overview

The Molex 105431-1107 is a Nano-Fit series PCB header designed for surface mount assembly. It features a single row with seven circuits and a 2.50mm (0.098 inch) mating pitch. The connector utilizes black resin housing with glow-wire capability and includes pick-and-place tape for automated manufacturing. Termination interfaces are plated with 0.76µm tin to ensure reliable soldering.

Headers, Male Pins Feature Summary

• Glow-wire capable construction for enhanced fire safety compliance
• Surface mount orientation optimized for automated pick-and-place processes
• Single-row male pin configuration with shrouded design

Headers, Male Pins Applications

• General electronic interconnections requiring surface mount headers
• Consumer electronics assemblies utilizing compact board-to-board connections
• Industrial control systems needing glow-wire rated components

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Molex datasheet to confirm exact plating thickness, packaging type, and reel specifications. Ensure compatibility with standard SMT reflow profiles and check for any recent regulatory updates regarding material declarations before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a 2.50mm pitch vertical header is required for surface mount applications. The single-row, seven-position layout suits low-density signal routing. Verify that the operating temperature range and current ratings align with the specific circuit requirements of the target application design.

Headers, Male Pins Part Context

This part belongs to the Nano-Fit family, characterized by compact form factors and high reliability. It serves as a standard interconnect solution within Molex's portfolio for general-purpose electronic assemblies, bridging connections between printed circuit boards in space-constrained environments.

Headers, Male Pins Replacement Considerations

Consult the official Molex series chart for direct substitutes with varying circuit counts or pitch sizes. Cross-reference compatible mating receptacles from the same Nano-Fit series to ensure mechanical and electrical compatibility without modifying the board layout.
