Overview

The SICK GTB10-P4212 is a block-shaped diffuse reflection photoelectric sensor from the G10 series. It features a polarized red light source and PNP output. The device has a maximum switching distance of 950 mm with a 90% diffuse reflectivity object. Dimensions are 20 mm x 50 mm x 39 mm. It utilizes a PinPoint-LED with an axis length of 625 nm and includes a five-turn potentiometer for setting.

Feature Summary

• Polarized retro-reflective technology for reliable detection on shiny surfaces
• Background suppression capability for consistent performance regardless of object color
• Adjustable sensitivity via integrated multi-turn potentiometer

Applications

• Automated assembly line object detection
• Packaging machinery presence verification
• Conveyor belt sorting systems

Procurement Notes

Verify the specific订货号 (Order Number) matches the required configuration, as suffixes may indicate different cable lengths or connector types. Confirm that the PNP output type aligns with the control system input requirements. Ensure the mounting bracket BEF-G10DC01 is included or ordered separately if needed for installation.

Selection Notes

Select this model when background suppression is required to distinguish objects from varying backgrounds. The polarized optical path is essential for detecting reflective targets. Verify the 950 mm switching range meets the application distance. Ensure the 20 mm width fits within the available mechanical space constraints.

Part Context

This component belongs to the SICK G10 series, designed for general industrial automation. It represents a compact solution for precise object detection tasks requiring high reliability in challenging lighting conditions. The series emphasizes ease of setup through adjustable parameters.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Cross-referencing requires matching technical specifications such as switching distance, output type, and mounting dimensions with alternative manufacturers' datasheets.
