1061481

Overview

The SICK model 1061481 is an IQ12-04BPSKT0SS01 inductive proximity sensor designed for precise object detection in industrial automation environments. It features a rectangular housing with dimensions of 12 mm x 40 mm x 26 mm and provides a sensing range (Sn) of 4 mm with a safe sensing range (Sa) of 3.24 mm. The device operates on DC 3-wire wiring and utilizes a PNP switching output with a normally open function. It supports a high switching frequency of 2,000 Hz and connects via a 3-pin M8 connector. The unit offers an enclosure rating of IP68, ensuring protection against dust and water immersion.

Feature Summary

• Compact rectangular housing design facilitates straightforward integration into space-constrained machinery.
• IP68 enclosure rating ensures reliable operation in harsh industrial conditions involving dust and moisture.
• High switching frequency of 2,000 Hz enables rapid response for fast-moving production lines.
• Different oscillator frequency technology enhances detection stability on challenging metallic surfaces.

Applications

• Automated assembly line component positioning
• Packaging machine object detection
• Material handling system presence verification

Procurement Notes

Verify the specific ordering suffix KT0SS01 to confirm the exact cable length and connector configuration required for your installation. Ensure compatibility with standard 24V DC control systems utilizing PNP inputs. Confirm that the M8 3-pin connector interface matches existing cabling infrastructure. Validate that the 4mm sensing range meets the physical requirements of the target objects.

Selection Notes

Select this model when a compact form factor and high-speed switching are critical for the application. The IP68 rating makes it suitable for washdown areas or dusty environments where standard sensors might fail. Consider the PNP output type to ensure compatibility with downstream PLC inputs. The different oscillator frequency feature is advantageous for detecting small or difficult-to-detect metal targets reliably.

Part Context

This component belongs to the IQ12 series of inductive proximity sensors from SICK. The series is characterized by its small footprint and robust performance in automated manufacturing. These sensors are engineered for general-purpose industrial detection tasks requiring high reliability and consistent measurement results across varying environmental conditions.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify mechanical mounting dimensions and electrical specifications against existing legacy components before substitution.

FAQ

What is the difference between the sensing range (Sn) and the safe sensing range (Sa)?

The sensing range (Sn) is the nominal distance at which the sensor triggers, specified as 4 mm. The safe sensing range (Sa) is the guaranteed operational distance, specified as 3.24 mm, ensuring reliable switching under all defined operating conditions.

How does the different oscillator frequency benefit detection?

The different oscillator frequency technology allows the sensor to maintain stable detection performance on challenging surfaces, such as those with varying conductivity or reflectivity, which might cause instability in standard sensors.
